Thursday, August 20, 2009

PROTOtype #1












...well, finally get the pictures of this board that I made last year. I did it to send to the 2008 Sacred Craft show but unforeseen events let it outside..
anyway, this board is roughly based on the air induction concept of 1 of the 3 Morey s early 70s prototypes and after some mails with B Mckee and 1 with G Loehr, I decided to made it.
sports: HYDROSLOTS; flat and S deck; normal entry rocker for a fish but heavy rockered in the last 2´, kick tail too; 60/40s rails extremely tapered out to tail; concave bottom channel fading out in the same line of the front fins; "2 in 4" speed d fins, well, i do these rear modificated fins to half of the fishes and work better backhand than the cqc normal ones.
2 4oz Aerialite fiberglass on top and 1 on the bottom; gloss coat deck, speed finish/bit of gloss on the bottom.
this is the most modern contemporary fish that I did and like may be some of you just saw, follow the concept of my tail area design

Sunday, August 16, 2009

custom fin


6 1/2H 4 1/2B; 35º; 3/8 max thickness tapered out to tip; medium more vertical cutaway; rigid; 20 oz volan fiberglass was used; Silver jewel adjust device; matte finish

Thursday, August 06, 2009

un huevo más







...2+1 mini egg with plenty of meat in chest and stance area. Sports a bit more area in the tail than what normally I shape in these dims. 60/40s semi full rails to hard; tucked edge all the way. Flat deck. Flat bottom with slight V in tail. Moderate rocker. 2x4oz top, 1 4oz bottom Aerialite fiberglass, Reichhold 203 resin. Gloss coat on top Speed finish bottom
